Variable Capacity Flat Bottom Tank

Item #:

VCT-F

Our Price:

make selection(s)

Size

Manufacturer

Quantity:

click on thumbnail to zoom

Description
Also in Fermenters & Tanks

These variable capacity "Air System" tanks with flat bottoms built in AISI 304 BA 18/10 stainless steel are ideal for fermenting or aging wine. They feature a smooth mirror finish on the inside for optimal cleanliness and an attractive textured exterior. Given the sizes they are excellent casks for cellars (ideal for vinification and storage).

DETAILS

Hand Pump/Guage with Inflatable Tube for air system included to seal lid
Marble Airlock Included
100% Adjustable Floating Pneumatic Lid which accepts Marble Airlock
Lid is easily adjusted to provide a minimum of headspace
Tanks 500 Liters and larger have welded 1.5" Tri Clamp port and Butterfly Valve
1000L and larger come with a Sample Port
All 18/10 AISI 304 Stainless Steel
Stands are an option to be purchased seperately, but storing and movement on pallets with a pallet jack works great
Lift Arm and Stand are Option Items Not Included
Other Special Order Options: Thermometer, Cooling Jacket, Sample Tap, Round Manhole, Ladder Support

SPECS:

MFR.		VOLUME DIM. (DIA. x HGT.)	DRAIN PORT	SAMPLE TAP	LIFT ARM
Marchisio	100 Liter	477x600 mm	1.0" NPT Valve
Toscana	100 Liter	420x750 mm	0.75" NPT Valve
Marchisio	200 Liter (std)	650x650 mm	1.0" NPT Valve
Toscana	200 Liter (std)	640x700 mm	0.75" NPT Valve
Marchisio	200 Liter (tall)	477x1200 mm	1.0" NPT Valve
Toscana	200 (tall)	525x1000 mm	0.75" NPT Valve
Marchisio	300 Liter	650x1000 mm	1.0" NPT Valve
Toscana	300 Liter	640x1000 mm	0.75" NPT Valve
Marchisio	500 Liter	790x1100 mm	1.5" Tri Clamp	YES
Toscana	500 Liter	720x1250 mm	1.5" Tri Clamp	YES
Marchisio	750 Liter	1000x1000 mm	1.5" Tri Clamp	YES
Marchisio	1000 Liter (std)	1000x1300 mm	1.5" Tri Clamp	YES
Toscana	1000 Liter (std)	1025x1250 mm	1.5" Tri Clamp	YES
Toscana	1000 Liter (tall)	930x1500 mm	1.5" Tri Clamp	YES
Marchisio	1500 Liter	1000x2000 mm	1.5" Tri Clamp	YES	YES
Toscana	1500 Liter	1150x1500 mm	1.5" Tri Clamp	YES	YES
Toscana	2000 Liter (std)	1320x1500 mm	1.5" Tri Clamp	YES	YES
Toscana	2000 Liter (tall)	1150x2000 mm	1.5" Tri Clamp	YES	YES
Marchisio	2150 Liter	1200x2000 mm	1.5" Tri Clamp	YES	YES

CUSTOMER PICK-UP OR TRUCK SHIPMENT ONLY! - We will contact you with actual shipping costs prior to finalizing the order or charging your credit card.
This item is not crated for shipping either when imported to the U.S. or shipped to our customers as the added weight would make them cost prohibitive to ship. Accordingly they may be received with very minor scratches not that dissimilar than they will receive during their normal use, but are guaranteed to arrive in working order.
