Variable Capacity Slope Bottom Tank with Jacket

Price: make selection(s)
  • Item #VCT-SJ
- +
Our Professional European built Variable Capacity Sloped (Inclined) Bottom Jacketed Tanks are constructed entirely of AISI 304 Stainless Steel, are built to our specifications and come standard with the Following:

DETAILS
  • AISI 304 Stainless Steel construction
  • 5% Sloped (Inclined) Bottom - Sloped bottom designed for ease of cleaning... Perfect for REDS, Cider, any beverage with a lot of solids that settle out
  • Welded Legs
  • Jacketed, Dimpled (see Details below)
  • Reinforced Rim
  • Full "Total" Drain Port with Tri-Clamp Ball Valve
  • Partial "Racking" Port with Tri-Clamp Ball Valve
  • Sample Tap
  • Manway Door
  • Sight Level Gauge
  • Ladder Support (1000L and larger)
  • Thermometer with ThermoWell
  • Lifting Rings for transport for tanks (1500L and larger)
  • Lift Arm for Lid (1000L and larger)
  • Winch (3000L and larger)
  • Inflatable Seal & Pump with Gauge
  • Marble Airlock
  • Additional customization available upon request
We stock tanks up to 4000 Liters. Call for pricing and availability of tanks larger than 4000 Liters.

* See our new Dish / Round Bottom Tanks - Best of both Conical and Slope in the same tank!


DETAILS:
MFR. CAPACITY
VOLUME DIM.
(DIA. x HGT.)
LEG
HEIGHT
TOTAL
HEIGHT
JACKET DRAIN
PORT (TC)
RACKING
PORT (TC)
SAMPLE
TAP
MANWAY
DIMENSIONS
LEVEL
GAUGE
LADDER
RACK
THERM.
& WELL
LIFT
RINGS
LIFT
ARM
REINF.
RIM
Marchisio  1000 Liter 1000x1300 mm  400 mm 1700 mm 500 mm, 1.5 m2 2.0" 1.5" YES 300 mm
YES YES YES YES YES YES
Zottel 1100 Liter 953x1500 mm 320 mm 1820 mm 400 mm, 1.1 m2 2.0" 1.5" YES 420x310 mm
YES YES YES YES YES YES
Marchisio 1500 Liter 1000x2000 mm 400 mm 2400 mm 500 mm, 1.5 m2 2.0" 1.5" YES 310x420 mm
YES YES YES YES YES YES
Zottel 1500 Liter 1115x1500 mm 360 mm 1860 mm 400 mm, 1.4 m2 2.0" 1.5" YES 420x310 mm YES YES YES YES YES YES
Zottel 2000 Liter 1275x1500 mm 360 mm 1860 mm 320 mm (2), 2.4 m2
2.0" 1.5" YES 420x310 mm YES YES YES YES YES YES
Marchisio 2150 Liter 1190x2000 mm 400 mm 2400 mm 750 mm, 2.4 m2 2.0" 1.5" YES 310x420 mm YES YES YES YES YES YES
Zottel 2450 Liter 1430x1500 mm 360 mm 1860 mm 320 mm (2), 2.7 m2 2.0" 1.5" YES 420x310 mm YES YES YES YES YES YES
Marchisio 3200 Liter 1430x2000 mm 400 mm 2400 mm 750 mm, 3.4 m2 2.0" 2.0" YES 420x530 mm YES YES YES YES YES YES
Zottel 3300 Liter 1430x2000 mm 360 mm 2360 mm 320 mm (2), 2.7 m2  2.0" 2.0" YES 530x400 mm YES YES YES YES YES YES
Zottel 3850 Liter 1275x3000 mm 360 mm 3360 mm 625 mm (2), 4.8 m2 2.0" 2.0" YES 530x400 mm YES YES YES YES YES YES
Marchisio 4000 Liter 1600x2000 mm 400 mm 2400 mm 750 mm, 3.8 m2 2.0" 2.0" YES 420x530 mm YES YES YES YES YES YES
Zottel 4850 Liter 1430x3000 mm 360 mm 3360 mm 625 mm (2), 5.4 m2 2.0" 2.0" YES 530x400 mm YES YES YES YES YES YES
Marchisio 5000 Liter 1600x2500 mm 500 mm 3000 mm 750 mm, 3.8 m2 2.0" 2.0" YES 420x530 mm YES YES YES YES YES YES
Marchisio 6000 Liter 1800x2500 mm 500 mm 3000 mm 900 mm, 5.1 m2 2.0" 2.0" YES 420x530 mm YES YES YES YES YES YES
Zottel 6400 Liter 1430x4000 mm 360 mm 4360 mm 725 mm (3), 9.2 m2 2.0" 2.0" YES 530x400 mm YES YES YES YES YES YES
Marchisio 7200 Liter 1800x2750 mm 500 mm 3250 mm 900 mm, 5.1 m2 3.0" 2.0" YES 420x530 mm YES YES YES YES YES YES
Marchisio 8000 Liter 1800x3000 mm 500 mm 3500 mm 900 mm, 5.1 m2 3.0" 2.0" YES 420x530 mm YES YES YES YES YES YES
Zottel 8000 Liter 1600x4000 mm 360 mm 4360 mm 900 mm, 5.1 m2 3.0" 2.0" YES 530x400 mm YES YES YES YES YES YES

We stock tanks up to 4000 Liters. Call for pricing and availability of tanks larger than 4000 Liters.

CUSTOMER PICK-UP OR TRUCK SHIPMENT ONLY! - We will call with actual shipping costs prior to shipping or charging your credit card.
This item is not crated for shipping either when imported to the U.S. or shipped to our customers as the added weight would make them cost prohibitive to ship. Accordingly they may be received with very minor scratches not that dissimilar than they will receive during their normal use, but are guaranteed to arrive in working order.
